The rugged one-piece speaker cabinet houses a high efficient class-D amplifier that drives high sensitivity two-way loudspeakers and limiter circuitry reduces distortion and increases intelligibility for guaranteed powerful and clear sound. Built-in digital audio player with optional CD player and interlinking transmitter/receiver package for extended transmission range. It offers an ideal public address solution for medium crowds.
Ideal Applications
- School classrooms & halls
- Places of worship
- Presentations, seminars and meetings
- Day-care activities; playground duty
- Indoor/outdoor gatherings
- Weddings & funeral services
- Shopping center & trade show presentations and promotions
- Street performers
- Aerobic and fitness centers
- Recreational and social activities
FEATURES:
- 145-watt power of loud and clear sound via high efficient class-D amplifier.
- Rugged one-piece molded enclosure houses 1 " titanium compression driver & 8 " woofer.
- Powerful and crystal-clear sound projection.
- Built-in or detachable receiver module option.
- Wireless receiver with 16 auto-scannable frequencies.
- One-touch Scan & ACT sync button for fast and easy channel set-up.
- Built-in Bluetooth music player for wireless audio streaming.
- A voice priority feature that mutes the music when wireless microphone is used.
- Built-in one-button alarm/siren for warning of threats.
- Built-in AC switching power supply for universal usage and fast battery charge.
- A smart 4-segment battery meter for accurate battery reading and charging status.
- Industry’s only MT-91 wireless interlinking transmitter option to interlink multiple MA-505 portables wirelessly to extend transmission range and expand coverage.
- Built-in cable storage compartment.
- AC and lithium rechargeable battery operation.
- Up to 8 hours of stand-by time per 4-hour full charge.
The product images and specifications shown on our website may differ from the actual products due to different versions.
| Model |
MA-505 |
| Name |
Portable Wireless PA System |
| Max. SPL |
105 dB |
| Drivers |
1" Tweeter & 8" Woofer |
| Frequency Range |
70 Hz – 14 kHz |
| Audio Inputs |
MIC IN: 1 × XLR, 1 × 1/4" (6.3 mm)
LINE IN: 1 × 1/8" (3.5 mm) |
| Audio Output |
LINE OUT: 1 × 1/8" (3.5 mm) |
| Amplifier |
Class D |
| Output Power |
145 W RMS, 248 W peak |
| Receiver Modules |
Up to 4 |
| Audio Players |
Bluetooth, CD/USB/SD player & recorder (optional) |
| Transmitter Modules |
MTM-91, MTM-24, MTM-58 (optional) |
| Extension Speaker |
1 × 1/4" (6.3 mm) |
| Other Functions |
VOP, TONE control, siren sound effect |
| Power Supply |
AC 100 – 240 V or DC 24 – 28 V |
| Battery |
Built-in one Li-ion battery pack (MB-35) |
| Battery Indicator |
4-segment indicators (25/50/75/100%) |
| Standby Time |
Up to 8 hours |
| Dimensions |
275 × 406 × 225 mm (W × H × D) |
| Weight |
Approx. 8.0 kg |
| Optional Accessories |
SC-505 carry bag, MS-70 tripod stand, MM-Series microphones |
| Note |
Patented. Telecom and safety regulations approved |
