The compact ESW-T4107-925H15 Desk Stand transmitter with microphone is an optional component for use with Audio-Technica's Engineered Sound Wireless systems (sold separately). The transmitter comes with a 15" hypercardioid ES925 gooseneck microphone that delivers clear, present dialog capture with a high level of surrounding noise rejection. There's a two-state LED mute status indicator light on the top panel with seven selectable custom colors for at-a-glance verification. The transmitter supports use while charging via USB for always-on availability. ESW systems (sold separately) employ DECT automatic frequency management technology, so there's no channel programming necessary. Remove the transmitter from the charger (sold separately), and it's ready to deliver interference-free wireless audio performance.

Audio-Technica ESW-T4107/925H15 Includes:

• AT8109a foam windscreen
• M44 mic case

Audio-Technica ESW-T4107/925H15 Features:

• 2-state RGB LED mute status indicator (7 selectable colors or off)
• Microphone reflects mute status color selection
• Transmitter can be used while charging via USB-C type connection
• Selectable mute operation (toggle, touch-to-talk, or touch-to-mute)
• Transmitter can be set to start either muted or unmuted
• Interchangeable ESW system microphone
• Cardioid pickup pattern for a high degree of isolation

Audio-Technica ESW-T4107/925H15 Specifications:

• ESW-4107
  • Modulation Mode
    • A-field: π / 2-BPSK
    • B-field: π / 4-QPSK
  • Microphone: ES Series modular gooseneck microphone-compatible
  • Battery: Lithium-ion battery LI-220 (included)
  • Battery Life: 17 hours, This varies depending on usage conditions.
  • Charging Time (USB): Approx. 2 hours 40 minutes, This varies depending on usage conditions.
  • USB Charging Connector: USB Type-C (USB 3.0)
  • Operating Temperature Range: - 5◦ C to +45◦ C (23◦ F to 113◦ F)
  • Dimensions: 90.5 mm (3.6") x 129.4 mm (5.1") x 47.4 mm (1.9") (W x D x H)
  • Weight (with battery) 535 g (19 oz)
• ES925
  • Element: Fixed-charge back plate, permanently polarized condenser
  • Frequency Response: 30-20,000 Hz
  • Low-Frequency Roll Off: 80 Hz, 18 dB/octave
  • Open Circuit Sensitivity: -40 dB (10.0 mV) re 1V at 1 Pa
  • Maximum Input Sound Level: 140 dB SPL
  • Dynamic Range: 112 dB
  • Signal-to-Noise Ratio: 66 dB
  • Phantom Power Requirements: 22-52V DC
  • Switches
    • Activation: on/off; LED Color: mic on, mic off;
    • Switch function: touch on/off, momentary on, momentary off;
    • Control: local, remote, LED remote; Flat, roll-off
  • Current Consumption: 8 mA
  • Weight: ES925H15/DS5: 703 g (24.8 oz)
  • Dimensions: ES925H15/DS5: 97.0 mm (3.82") W x 130.0 mm (5.12") D x 334.2 mm (13.16") H
• Output Connector: TB5M-type
• Pickup Pattern: ESE-Ha hypercardioid (100°)
